| Supported CPU |
AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors (Socket AM5) |
| Chipset |
AMD B650 |
| Form Factor |
mATX (243.84 mm × 243.84 mm) |
| Memory Type |
DDR5 |
| Memory Slots |
2 |
| Max Memory |
96 GB |
| Supported Memory Speed |
Up to 6800+ MHz (OC) / 4800 MHz (JEDEC) |
| PCIe Slots |
1 × PCIe 4.0 x16 (from CPU) 1 × PCIe 3.0 x1 (from Chipset) |
| M.2 Slot |
1 × M.2 PCIe 4.0 x4 (from CPU, supports 2280/2260) |
| SATA Ports |
4 × SATA 6Gb/s |
| RAID |
RAID 0, 1, 10 (SATA only) |
| Graphics Outputs |
1 × HDMI 2.1 (4K@60Hz) 1 × VGA (up to 2048×1536 @50Hz) |
| LAN |
Realtek RTL8125BG 2.5 Gbps |
| Audio |
Realtek ALC897 7.1-Channel HD Audio |
| Rear USB Ports |
4 × USB 3.2 Gen1 Type-A 2 × USB 2.0 |
| Front USB (via headers) |
2 × USB 3.2 Gen1 Type-A 4 × USB 2.0 |
| Internal I/O |
1 × 24-pin ATX + 1 × 8-pin CPU power 1 × CPU Fan + 2 × System Fan RGB + ARGB headers TPM, COM, Clear CMOS etc. |
| TPM |
1 × TPM pin header (Supports TPM 2.0) |
| Warranty |
3 Years Manufacturing Warranty |
