| Supported CPU |
AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors (Socket AM5) |
| Chipset |
AMD B650 |
| Form Factor |
mATX (243.84 mm × 243.84 mm) |
| Memory Type |
DDR5 |
| Memory Slots |
4 |
| Max Memory |
128 GB |
| Supported Memory Speed |
Up to 7600+ MHz (OC) / 7200–4800 MHz |
| PCIe Slots |
1 × PCIe 4.0 x16 (x16/x8/x4 depending on CPU) 1 × PCIe 3.0 x1 |
| M.2 Slots |
2 × M.2 PCIe 4.0 x4 (from CPU, support 2280/2260) |
| SATA Ports |
4 × SATA 6Gb/s |
| RAID |
RAID 0, 1, 10 (SATA) RAID 0, 1 (M.2 NVMe) |
| Graphics Outputs |
1 × HDMI 2.1 (4K@60Hz) 1 × DisplayPort 1.4 (4K@60Hz) |
| LAN |
Realtek RTL8125BG 2.5Gbps |
| Wireless |
Wi-Fi 6E + Bluetooth 5.3 (AMD module, pre-installed in M.2 Key-E) |
| Audio |
Realtek ALC897 7.1-Channel HD Audio + S/PDIF output |
| Rear USB Ports |
1 × USB 3.2 Gen2x2 Type-C (20Gbps) 1 × USB 3.2 Gen2 Type-C (10Gbps) 3 × USB 3.2 Gen2 Type-A (10Gbps) 2 × USB 3.2 Gen1 Type-A (5Gbps) 2 × USB 2.0 |
| Front USB (via headers) |
1 × USB 3.2 Gen2 Type-C 2 × USB 3.2 Gen1 Type-A 4 × USB 2.0 |
| Internal I/O |
1 × 24-pin ATX, 2 × 8-pin CPU power 1 × CPU Fan, 1 × Pump Fan, 3 × System Fan RGB/ARGB headers, TPM header, Clear CMOS, Flash BIOS button etc. |
| Warranty |
3 Years Manufacturing Warranty |
